| 材质： |
聚氨脂橡胶 |
用途： |
各种大小型船舶、码头、港口、船坞、游艇码头、船艇、游艇等防撞 |
| 形状： |
长柱形 圆柱形 椭圆形 |
直径： |
按需要 |
|
名称规格 Name specifications |
D（mm） |
L（mm） |
压缩60% Compression 60% |
预埋U环直径 Embedded U circular diameter（ mm） |
吊挂链条直径Hanging chain diameter
（mm） |
|
反力counter-force（kn） |
吸能量Absorb energy（kn-m） |
|
ф300*500 |
300 |
500 |
38 |
1.8 |
|
|
|
ф400*800 |
400 |
800 |
56 |
2.6 |
|
|
|
ф1000*1500 |
1000 |
1500 |
205 |
49 |
ф40 |
M22 |
|
ф1000*2000 |
1000 |
2000 |
274 |
64 |
ф40 |
M22 |
|
ф1200*2000 |
1200 |
2000 |
337 |
93 |
ф45 |
M25 |
|
ф1500*3000 |
1500 |
3000 |
624 |
216 |
ф50 |
M25 |
|
ф2000*3500 |
2000 |
3500 |
990 |
456 |
ф50 |
M28 |
|
ф3000*6000 |
3000 |
6000 |
2460 |
1695 |
ф80 |
M38 |
|
ф4500*9000 |
4500 |
9000 |
19650 |
7860 |
ф80 |
M48 |
选择海伦 信赖海伦
喷涂型聚氨酯漂浮护舷采用当今世界上最先进的喷涂聚脲弹性体技术生产，该技术是国外近十年来开发研制的一种新型无溶剂、无污染的绿色施工技术，产品特点如下：
1、芯材为闭孔高回弹泡沫，质量小，吸能性好。芯材为闭孔高回弹泡沫式固体，即使破损也不会沉底。
2、外皮保护层－喷涂型聚脲弹性体（SPUA）被称为耐磨橡胶其耐磨性是碳钢的10倍，是环氧树脂的3-5倍；耐油性与丁腈胶媲美；拉伸强度、伸长率、撕裂强度在户外暴晒四年后，基本保持在初始强度状态；
3、普通管道防腐材料如熔结环氧粉末的耐盐雾试验一般不超过500ｈ，实际使用寿命在10年以下；0.5ｍｍ喷涂型聚脲弹性体10000ｈ盐雾试验无任何腐蚀现象，预计使用寿命高达50年以上。
4、聚脲保护层为芳香族涂层体系100％固含量，不含任何挥发性有机物，暴露在紫外线下需要很高稳定性、耐候性好；可在120℃下长期使用，具有良好的热稳定性。
5、聚氨酯漂浮护舷重量轻，护舷变形量大，适应性强，倾斜压缩性能好，它与一般橡胶护舷相比吸收能量大，而产生的反作用力小
6、性能可靠，安装方便，保养费用低，美观实用。
7、ＳＰＵＡ喷涂技术生产护舷克服了使用模具的局限性，在制作中不受产品尺寸限制，满足客户对制品的不同尺寸要求
Choose Helen trust Helen
Solid pu the foam fender (by ball) the biggest characteristics:
1. With floating performance, from influence of the tides.
2. Bright colors may according to the customer request to provide all sorts of color.
3. Compared with inflatable fenders, use the process does not need not inflatable, not afraid, afraid, afraid delimit plunge friction, resistant to salt water, acid and alkali resistant use life for 30 to 50 years, is safe and free maintenance.
4. Solid, light weight, convenient installation mobile.
5. Compressed 60% when the force has grown significantly, and absorb energy is extremely high
We have various types, can be made according to the customer request, a high degree of human nature.
The company has been devoting to ship water use vista on heavy air move, float; Let reservoir and wreck removal, heavy handling ship goods used of research and development, production and sales. High quality materials and strict production process manufacturing products, outside the sightseeing, entity wear resistance, oil resistance, bearing, ageing resistance, high alkaline acid, good air-tightness, high strength and long service life.
At present the product sell well in southeast Asia, Russia, the Middle East, Australia, south and North America, South Africa, Western Europe and other countries and areas, and many famous brand and abroad such as STAR ONE, VRC, such as BENDA successful cooperation, be they of the excellent supplier in China.
The company will continue to adhere to win-win cooperation, be the first spirit, makes every effort to a high starting point, high standard, high efficiency and development, with a brand new enterprise face, scientific management, advanced production equipment and technology, excellent enterprise credit to cooperate with the domestic and foreign friends, sharing success
Rubber balloon, new whole winding high strength up heavy move balloon, rubber fender (by ball), get together ammoniac EVA ester fender (by ball) yacht by ball (the touch pad) Marine balloon, fluctuation water balloon etc. Product.
